Alat uji getaran 802EN memiliki pengulangan yang baik. Alat ini dapat dengan cepat memeriksa hampir semua peralatan mekanis di pabrik berdasarkan getaran, kecepatan, dan percepatan secara keseluruhan. 802EN mudah digunakan, efisien, dan cepat untuk personel pemeliharaan di pembangkit listrik, metalurgi, petrokimia, makanan, dan industri lainnya.
FITUR Fluke 802EN
- Tiga mode pengujian untuk memenuhi lingkungan pengujian yang kompleks di bidang industri
- Kemampuan pengulangan yang tinggi untuk memastikan keakuratan pengujian berkelanjutan
- Pengukuran satu tombol untuk mendapatkan hasil penilaian dalam 6 detik
- Penyimpanan data 99 set, tinjauan secara real-time
SPESIFIKASI Fluke 802EN
| Internal Piezoelectric Accelerometer | ||
| Sensitivity (typical) | 10.00 mV / m/s² ± 5% (1 g = 9.8 m/s²) | |
| Measurement | ||
| Acceleration | Range | 0.1 m/s² to 199.9 m/s² peak (rms √2) |
| Resolution | 0.1 m/s² | |
| Accuracy | ± (5 % + 2 dgt) (LO: 10 Hz to 1 kHz) | |
| ± (10 % + 5 dgt) (HI: 1 kHz to 10 kHz) | ||
| Velocity | Range | 0.1 mm/s to 199.9 mm/s rms |
| Resolution | 0.1 mm/s | |
| Accuracy | ± (5% + 2 dgt) (10 Hz to 1 kHz) | |
| Displacement | Range | 0.001 mm to 1.999 mm peak-peak (rms 2√2) |
| Resolution | 0.001 mm | |
| Accuracy | ± (5 % +2 dgt) (10 Hz to 1 kHz) | |
| Piezoelectrical Accelerometer | ||
| Typical frequency response | 10 Hz to 15 kHz | |
| Amplitude Units | ||
| Acceleration | g, m/s² | |
| Velocity | mm/s | |
| Displacement | mm | |
| External Piezoelectrical Accelerometer | ||
| DC bias voltage | 6 V dc to 7 V dc | |
| DC bias current | 3.5 mA | |
| Note: Other specifications are the same as those of the internal piezoelectric accelerometers | ||
| Battery | 2 AAA, IEC LR03 | |
| Battery life | 25 hrs for measurement | |
| Dimensions (L x W x H) | 24.1 x 7.1 x 5.8 cm | |
| Weight | 220 g | |
| Audio port | Stereo audio output jack (3.5 mm Audio Plug) | |
| External sensor port | M12 plug | |
| Environment | ||
| Operating temperature | -10 °C to 50 °C | |
| Storage temperature | -30 °C to 60 °C | |
| Operating humidity | 30% to 90% RH (non-condensing) | |
| Operating altitude | 2,000 m | |
| Storage altitude | 12,000 m | |
| Ingress Protection | IP 40 | |
| Vibration limit | 500.0 m/s² peak | |
| Drop test | 1 m | |
| Electromagnetic Compatibility (EMC) | International IEC 61326-1: Portable, Industrial Electromagnetic Environment; CISPR 11: Group 1, Class A | |
