TM-4100 Tacho Meter dapat digunakan untuk berbagai jenis peralatan seperti konveyor, peralatan pendingin, pengering, elevator, kincir angin, pengumpan putar, dan penggiling. Ini tersedia untuk aplikasi kontak (dengan tool kit 4100K) dan non-kontak. Non-kontak dapat berukuran dari 40mm hingga 500mm.
FITUR Tenmars TM-4100
- LCD besar 6 digit dengan lampu latar.
- Mengukur dengan keluaran cahaya spektrum tampak merah.
- Jarak pengukuran: 50~500mm.
- Penyimpanan data manual: 300 data.
- Pencatat data USB hingga 20.000 data (TM-4100D).
SPESIFIKASI Tenmars TM-4100
| Models | TM-4100 | TM-4100D (USB datalogger) |
| Display | 6 digits backlit LCD | |
| Detection distance | 50mm to 500mm (1.58 to 19.7) | |
| Measuring indicator | The LCD display RING with a buzzer sound (or off) | |
| Sampling period | 62.5ms to 2s | |
| Operating temp/humidity | 0~40°C;25% to 75% RH | |
| Storage temp/humidity | -10~60°C;0% to 80% RH | |
| Memory capacity | 300 data sets | 20,000 data sets |
| Power supply | 9V battery x1 | |
| External power | AC 100~240V to DC 9V/0.5A | |
| Battery life | About 30 hours (buzzer off) | |
| Dimension | Approx. 186x76x36mm (LxWxH) | |
| Weight | Approx. 200g | |
| Accessories | Battery x1, carrying case x1, reflective tape x1 sheet, MINI USB 4P (MALE) to USB cable x1 (TM-4100D) | |
| Accuracy | AVG ON | AVG OFF |
| Up to 9,999 counts | ±1dgt | ±10dgt |
| 10,000 counts | ±2dgt | ±20dgt |
| 20,000 counts or more (r/min mode only) | ±20dgt | ±100dgt |
| Period measurement only | ±0.5% rdg is added to above-mentioned accuracy | |
| Period measurement (ms)
| 1 | 0.6000 to 1.9999 | 0.6000 to 1.9990 | – | – |
| 2 | 2.000 to 19.999 | 2.000 to 19.990 | 3.000 to 19.999 | 3.000 to 19.990 | |
| 3 | 20.00 to 199.99 | 20.00 to 199.90 | 20.00 to 199.99 | 20.00 to 199.90 | |
| 4 | 200.0 to 1999.9 | – | 200.0 to 3999.9 | 200.0 to 399.0 | |
| Count measurement (count) | 1 | 0 to 999999 (input conditions up to rotational speed measurement upper limit) | |||
| Mode
| Range
| Contactless measurement | Contact measurement | ||
AVG=ON | AVG=OFF | AVG=ON | AVG=OFF | ||
| Rotational speed measurement (r/m) | 1 | 30.00 to 199.99 | – | 15.00 to 199.99 | – |
2 | 200.0 to 1999.9 | 300.0 to 1999.0 | 200.0 to 1999.9 | 150.0 to 1999.0 | |
3 | 2000 to 19999 | 2000 to 19990 | 2000 to 19999 | 2000 to 19999 | |
4 | 20000 to 99990 | 20000 to 99990 | – | – | |
| Rotational speed measurement (r/s | 1 | 0.5000 to 1.9999 | – | 0.2500 to 1.9999 | – |
2 | 2.000 to 19.999 | 5.000 to 19.990 | 2.000 to 19.999 | 2.500 to 19.990 | |
3 | 20.00 to 199.99 | 20.00 to 199.90 | 20.00 to 199.99 | 20.00 to 199.90 | |
4 | 200.0 to 1600.0 | 200.0 to 1600.0 | 200.0 to 333.0 | 200.0 to 333.0 | |
| Speed Measurement | Range | AVG ON | AVG OFF |
| m/min
| 1 | 1.500 to 19.999 | – |
| 2 | 20.00 to 199.99 | 15.00 to 199.90 | |
| 3 | 200.0 to 1999.9 | 200.0 to 1999.0 | |
| m/s
| 1 | 0.0250 to 1.9999 | 0.2500 to 1999.0 |
| 2 | 2.000 to 19.999 | 2.000 to 19.990 | |
| 3 | 20.00 to 33.30 | 20.00 to 33.30 |
