Hioki 3664 optical power meter untuk mengukur daya optik dari cahaya spasial. Ini sangat ideal untukmenguji daya optik dari sumber cahaya laser dan sumber cahaya LED dari peralatan audio dan videoseperti Blue–Ray dan DVD recorder, drive, dan mesin fotokopi. Sensor optik opsional untuk meteran listrikyang dipertukarkan dan sensitivitas mereka dapat disesuaikan secara independen.
Features Hioki 3664 optical power meter
- Kompak dan ringan
- Ideal untuk di mana saja mulai dari produksi hingga R & D dan pemeliharaan
- konektivitas USB
- penskalaan
- Pengukuran MAX/MIN/AVG
- Layar LCD ukuran besar
- Keluaran analog
- 4,5 digit dan rentang dinamis yang luas dengan resolusi 0,01dBm
- Koreksi otomatis sensitivitas sensor menggunakan input panjang gelombang pengukuran
Ukur W dan dBm - Kompatibel dengan sensor yang berbeda
| Specification Hioki 3664 optical power meter | |||
| Optical power measurement | W, dBm | ||
| Range setting | Auto (Manual setting available) | ||
| Accuracy | ±0.7% (±5% in combination with the optional sensor) | ||
| Wavelength Sensitivity Compensation | Can be set for every 1nm. Automatic compensation for the sensor’s sensitivity Max. 10 wavelengths preset (including initial value for a sensor) | ||
| Scaling | Can be set for each wavelength. | ||
| Relative Measurement | Display the relative value to the measured value or set value. (Displayed value = Measured value – Reference value) •Reference value can be set from the measured value or manual input. •Settable range: 0.001nW to 1.9999W (-90.00dBm to 33.00dBm) | ||
| Display | 4-1/2 digit, (19999 max.), Display resolution: 0.01dBm / 0.01dB | ||
| Measurement Display Unit | nW, mW, mW, dBm, dB | ||
| Wavelength Display | 4 digit, Unit: nm | ||
| Display Update Rate | 330ms approx. | ||
| MAX/MIN display | Maximum and minimum value display while measurement | ||
| Average Display | Display the moving average value. Averaging times: 2 to 100 | ||
| Analog Output | 1V approx. when the sensor calibration point input | ||
| Output Resistance | 50Ω | ||
| Output Connector | ø3.5 mini jack | ||
| Interface | Output measurement value and remote control | ||
| Auxiliary Functions | Auto power save, Setting backup, Battery check | ||
| Safety | EN61010-1: 2001 Pollution degree 2 | ||
| Power Supply | AA (LR6) × 4, AC adapter (9445-02 | ||
| Max. rated power | 1.6VA | ||
| Continuous Battery Operation | 60 hours approx. (continuous use with the 9742 at calibration point input) | ||
| Dimensions and Weight | 85(W) × 160(H) × 35(D) mm, 270g (excluding batteries) | ||
