Meter ini khusus dikembangkan untuk mengukur atau memantau medan elektromagnetik, misalnya: stasiun telepon seluler, peralatan rumah sakit, radar, oven gelombang mikro, pekerjaan radiasi, antena TV, stasiun radio, peralatan las, peralatan memanggang, televisi, komputer, pabrik, laboratorium, dan lingkungan lainnya…dll.
FITUR Lutron EMF-819
- Penguji EMF RF 3 Axis, aplikasi serbaguna.
- Rentang frekuensi hingga 3 GHz, untuk memantau nilai EMF frekuensi radio yang luas atau mendeteksi kebocoran gelombang mikro.
- Rentang pengukuran: 0 hingga 199,99 V/m, 0 hingga 99,999 W/m2 0 hingga 9,9999 mW/cm2
Penahanan data, Penahanan puncak. Rekam (Nilai maks., min.). - Probe frekuensi, EP-05H disertakan.
- Tas jinjing keras disertakan.
- Antarmuka komputer RS232/USB.
- LCD ukuran besar, Sirkuit mikrokomputer.
- Didukung oleh baterai DC 9V atau adaptor DC 9V.
SPESIFIKASI Lutron EMF-819
| General Specifications | ||
| Circuit | Custom one-chip of microprocessor LSI circuit. | |
| Display | LCD size : 58 mm x 34 mm. | |
| Measurement Unit | V/m, mW/cm^2, W/m^2. | |
| < 2 dB. | ||
| Probe structure | 3 Axis. | |
| Probe Input Impedance | 50 OHM | |
| Sensor Structure | Semiconductor | |
| Frequency Team Selection | Two points selection : Normal, 2.45 GHz. | |
| Data Hold | Freeze the display reading. | |
| REC Function | Record Maximum & Minimum value. | |
| Power off | Auto shut off saves battery life or manual off by push button. *Can default auto power off or manual power off. *When default auto power off , power will off automatically after 10 min. if no button be pressed | |
| Peak Hold | To latch the peak measurement value. | |
| Alarm Setting | Buzzer will sound when display over the setting value. | |
| Sampling Time | Approx. 1 second. | |
| Low Battery Indicator | When display show Low battery Indicator, it should change the batteries. | |
| Data Output | RS 232 PC serial interface. | |
| Operating Temperature | 0 to 50°C | |
| Operating Humidity | Less than 80 %RH. | |
| Power Supply | DC 9 V battery ( 006P ) * Heavy duty or Alkaline type DC 9V adapter input. | |
| Power Current | Approx. DC 5.95 mA | |
| Weight | 425 g/ 0.94 LB. | |
| Dimension | Main instrument : 200.0 x 76.2 x 36.8 mm Probe : 70 mm ( diameter) x 240 mm ( length) | |
