Alat pengukur intensitas cahaya dengan fungsi data logging, bisa koneksi ke PC untuk olah data
Sensor bisa dilepas atau dipasang untuk fleksibilitas penggunaan.
FITUR TASI TA632B
- Produk bersertifikat CE
- Tampilan layar warna 5 digit, maks 99999
- Rentang pengukuran otomatis: 0~200.000Lux
- Pengukuran satuan Lux/FC
- Pengukuran nilai maks/min
- Pengaturan alarm batas atas/bawah
- Pengunggahan data
- Koefisien sumber cahaya yang ditentukan sendiri
SPESIFIKASI TASI TA632B
- Display: 5-digit color screen display, max 99999
- Measurement range: 0~200,000Lux 999.9Lux，99999Lux，1999×10Lux
- Resolution LUX：<1000:0.1LUX；≥1000:1LUX
- FC：<100:0.1FC； <1000:0.1FC；≥1000:1FC
- Accuracy ±(3%+5Lux)(calibrated under the standard incandescent lamp at color temperature 2856°K )
- ±(6%+5Lux)other visible light
- cosine angle deviation feature
- 30° ±2%
- 60° ±6%
- 80° ±25%
- Light sensor: Silicon photo-diode and spectral response filter
- Operating environment
- Temperature: -10～50°C, Humidity:＜80%RH, Altitude:<2000m
- Storage environment
- Temperature: -10～50°C, Humidity:＜70%RH(remove the battery)
- Sampling rate: Approx. 8 times/s
- Incident angle: 120°
- Repeated test deviation: 2%
- Spectral range: 400~ 700nm
- Auto off: 15 minutes
- Data upload: Only TA632B
- Power: 3 x AA battery
- Standard accessories: Color box,cloth bag,instruction manual
- Product size 256X67X35mm
- Product weight 250g (not including battery)
- Single package size 295 x 95 x 45mm
