| Optical Fiber Requirements |
| Material |
silica glass |
| Fiber Count / Profile Types |
Single / SMF (G.652), MMF (G.651), DSF (G.653), NZDSF (G.655), BIF (G.657) |
| Fiber Diameter |
Cladding diameter: 80 µm ~ 150 µm, Coating diameter: 100 µm ~ 1,000 µm |
| Cleave Length |
5~16 mm with coating clamp |
| Standard Performance |
| Splice Loss (typical) |
SMF: 0.02 dB, MMF: 0.01 dB, DSF: 0.04 dB, NZDSF: 0.04 dB |
| Return Loss (typical) |
≤60 dB |
| Splicing cycle time (typical) |
6 sec (SM G652 Quick Mode), 8 sec (Auto Mode) |
| Heating cycle time (typical) |
15 sec (FPS-61-2.6 sleeve, S60mm 0.25) |
| Splice & Heat cycles per battery full charge |
approx. 300 cycles |
| Fiber view & magnification |
two CMOS cameras observation, 350X (zoom: 700X) for X or Y single axis view, max. 250X for both X & Y dual axis view |
| Proof Test |
1.96 – 2.09N |
| Applicable Protection Sleeve |
60 mm, 40 mm and Sumitomo Nano sleeves |
| Programs |
| Splicing programs |
max. 300 (40 are pre-optimized, 260 editable by user) |
| Heating programs |
max. 100 (23 are pre-optimized, 77 editable by user) |
| Functions |
| Splice image capture / Splice data storage |
200 images / 10 000 splice data (internal memory only)
50 200 / 20 000 (with 16 GB SD card) |
| Universal clamps for 250µm, 900µm tight & loose buffer fiber |
Provided |
| Reversible coating clamps |
Provided |
| Onboard user training video |
Provided |
| Automatic fiber identification |
Provided (SMF / MMF / other) |
| Automatic arc calibration |
Automatically compensates for environmental condition changes |
| Display of remaining Splice & Heat cycles |
Provided (Battery mode) |
| Terminals |
| DC output |
DC12 V (for JR-6) |
| USB port |
USB 2.0 (mini-B type) |
| Storage media |
SD / SDHC memory card MAX 32 GB |
| Power Supply |
| AC input |
100 ～ 240 V, 50 / 60 Hz (ADC-16) |
| DC input |
10 ～15 V |
| Battery Pack |
Li-ion 10.8 V, 6,400 mAh (BU-16) |
| Mechanical Parameters |
| Monitor |
5.0″ touch screen color LCD |
| Dimensions |
128(W) x 154(D) x 130(H) mm (without anti-shock rubber) |
| Weight |
1.7 kg (without battery), 2.0 kg (with battery BU-16) |
| Electrode life |
6 000 arc discharges |
| Environment |
| Operating conditions |
Altitude 0～6,000 m, Temperature -10～+50°C, Humidity 0～95% (non-condensing), Wind velocity up to 15 m/s |
| Storage conditions |
Temperature -40～+80°C, Humidity 0～95% (non-condensing), Battery -20～+30°C (long term) |
| Dust resistance |
Equivalent to IP5x (Operates normally after 8 hours in a dust chamber (containing dust of particle size 25 µm or below) |
| Water resistance |
Equivalent to IPx2 (Operates normally after being exposed to water dripping at 3mm/min. for at least 2.5 min on each of 4 surfaces tilted at 15°) |
| Shock resistance |
Drop from 76cm on 5 faces (excluding top face) |
store manager
Jamal Awaludin –
SUMITOMO Type-Z1C adalah fusion splicer dengan pemantauan inti langsung untuk penyambungan kabel fiber optik sangat cepat di setiap kondisi lapangan. Design dan kemampuan alat sangat cepat dan kompak dan ringan.
